Compact, powerful decoder & descrambler

ProView™ is a compact, single-channel commercial decoder and descrambler for your general-purpose primary distribution applications. Enhance your contribution workflows with powerful decoding and descrambling capabilities for ultimate efficiency.

Expand channel lineup

By integrating DVB-S/S2/S2X demodulation with the streaming of descrambled content over IP, ProView 7100 enables operators to quickly and cost-effectively launch new services while leveraging their existing IP or legacy ASI infrastructure.

Preserve pristine video quality

The flexible hardware design is easily reconfigured with firmware upgrades, enabling seamless adaptation to new inbound video formats and codecs, such as MPEG-4 AVC and HEVC.

Video processing with ProView 7100

The ProView 7100 IRD harnesses a flexible and modular design to address the vast spectrum of content reception applications, from decoding, descrambling and multiplexing of multiple transport streams to MPEG-4 to MPEG-2 transcoding.

Includes an advanced and dense multichannel descrambler and a flexible hardware design that is easily reconfigured with firmware upgrades.

Superior transcoding

One decoding or transcoding cards for SD/HD MPEG-2 and AVC formats

Expanded inputs

Simultaneously receive content over DVB-S/S2/S2X, ASI and IP

Easy-to-use

Control mass configuring, monitoring and automated redundancy

High-fidelity decoding

MPEG-2 4:2:0 8-bit and AVC and HEVC 4:2:2 10-bit precision decoding and descrambling

T2-MI deframming to MPEG TS

Up to four simultaneous T2-MI-to-TS conversions

ProView 7100 technical specifications

Input/Output interfaces

RF input interfaces
DVB-S/S2/S2X: Four L-band
ASI input: Four
2x GbE input ports: up to 8 simultaneous MPEG over IP SPTS/MPTS

TS output interfaces
ASI output: Four (duplicate or independent)
2x GbE output ports: Up to 16 simultaneous MPEG over IP SPTS/MPTS

TS processing

Eight transport stream (TS) multiplexing (any to any)

Seamless switching between two incoming, identical TS on different networks

Service-level remultiplexing from any input to any output

Service-level filtering

High-accuracy PCR restamping

PSI/SI processing and regeneration

T2-MI deframing to MPEG TS

Auto generation or passthrough of PSI/SI tables

CA signaling removed when descrambling

Audio/video decoding & transcoding

Four stereo pairs per video channel

Audio codecs
MPEG-1 Layer-II, Dolby® Digital (AC-3) stereo down-mix, Dolby Digital 5.1 passthrough, Dolby Digital Plus (E-AC-3), Dolby E passthrough, AAC, Audio leveling

Video decoding codecs
MPEG2 SD/HD 4:2:0 4:2:2, MPEG4 SD/HD 4:2:0 4:2:2, HEVC

Video decoding formats
MPEG-2 SD: 4:2:0 MP @ ML, 4:2:2 @ ML
MPEG-2 HD: 4:2:0 MP @ HL, 4:2:2 P @ HL
MPEG-4 AVC SD: 4:2:0 MP @ L3, 4:2:2 HP @ L3
MPEG-4 AVC HD: 4:2:0 MP @ L4.0 / HP @ 4.1, 4:2:2 @ HiP/Hi10P/Hi422P @ L4.1 (8 and 10 bit)
HEVC HD: Main/Main 10, 1080i/720p 4:2:0 @L4.0, 1080P and 4:2:2@L4.1 (8 and 10 bit)

Maximum video rate
SD formats: 480i @ 29.97 fps, 576i @ 25 fps, 480p @ 59.94 fps
HD formats: 1080p @ 50, 59.94 fps, 1080i @ 29.97, 30, 25 fps, 720p @ 59.94, 50, 60 fps

Video transcoding
Up to eight channels (from the same input TS)

Video inputs
MPEG-4 AVC SD, MPEG-4 AVC HD

Video outputs
MPEG-2 SD, MPEG-2 HD, MPEG-4 AVC, MPEG-4 AVC HD

Video descrambling & processing

HD Video Down Converted to SD with Aspect Ratio Conversion: Letterbox, center cut, AFD

Aspect Ratio Conversion: 16:9 to 4:3

VBI Reinsertion: Composite video, embedded in SDI

Descrambling: Four TS with four DVB CAM slots and BISS

Video & audio interfaces

Video outputs
Composite Video Interfaces: Two (per video channel)
SD/HD/3G-SDI with Embedded Audio: Two (per video channel)

Audio outputs
Stereo Pairs: Four (per video channel)
Analog Audio Stereo Pairs: Four (balanced) 600 Ω
Digital audio (AES/EBUS/P-DIF): Four
Digital Audio Interfaces Modes: Four (balanced) Stereo, joint stereo, dual channel, single channel

Control & monitoring

Web browser interface

Ethernet – RJ45 10/100BaseT control interface

Front panel keypad and LCD

NMX management system for monitoring

Presets

SNMP traps and alarms

Telnet

Terminal via RS-232 or RS-485

XML interface for control monitoring

use-case-image-proview-7100-ird

ProView 7100 is ideal for your primary distribution needs

IP headend deployment

The flexible, high-density, multichannel ProView 7100 allows users to deploy an IP headend easily and cost-effectively.

DVB-T/T2

Designed for automatic redundancy of 1+1 TS streams coming from two different paths handling different delays or coming from two different equipment.

Deliver broadcast quality

Perform HD down-conversion and aspect ratio adaptation to generate broadcast-quality baseband analog video and audio.
